• Grade 6 high tensile steel body and pin, quenched and tempered.
• Hot dipped galvanised finish.
• Conforms to BS EN 13889 (from 0.5t to 25t) and meets the performance requirements of US Fed. Spec. RR-C-271 type IVA class 2, grade A.
• From 2t and upward these shackles comply with ASME B30.26.
• Minimum breaking load is 6 times the W.L.L.
• Temperature range -40°C up to +200°C.

• Certs available  2.1 Works certificate to EN 10204 – Type 2.1
  Statement of compliance with the order.  3.1 Inspection certificate to EN 10204 – Type 3.1
  Statement of compliance with the order, stating the results of material specific inspection.  MTC Manufacturer test certificate
  Statement of compliance with the order, stating results of tested samples from a production batch. Products not individually tested.  DoC UKCA / EC Declaration
  In accordance with the machinery directive 2006/42/EC and the latest amendments. Depending on product can be; UKCA and/or EC Declaration of: Conformity, Incorporation or General certificate.  DNV GL 2.7-1 Certificate for offshore containers DNV GL 2.7-1
  DNV GL Certificate. Type approved to DNV standards DNV-ST-E271-2.71 Offshore containers.

G-4163H

Product Code	W.L.L.	A	B	C	D	E	F	G	H	I	J	K	L	M	N	Weight	PDF
	t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	kgs
GPCSAB2	2	13.5	16	34	13	22	51	32	89	102	58	19	15	48.4	27	0.47
GPCSAB3.25	3.25	16	19	40	16	27	64	43	110	122	75	23	15	53.7	31.8	0.81
GPCSAB4.75	4.75	19	22	46	19	31	76	51	129	143	89	26	15	60.1	36.5	1.32
GPCSAB6.5	6.5	22	25	52	22	36	83	58	144	160.5	102	29	15	65.5	41.3	1.92
GPCSAB8.5	8.5	25	28	59	25	43	95	68	164	183	118	32	15	70.5	46	2.77
GPCSAB9.5	9.5	28	32	66	28	47	108	75	185	201	131	34	15	74	50.8	3.91
