Grade 80 Weld on D-Ring – G80WDR

Click to enlarge Click to enlarge


G80WDR

Code Model No W.L.L A B D M Weight
(tonnes) (mm) (mm) (mm) (mm) (kgs/each)
G80WDR1 SLR344-1T 1.12 41 78.5 13 37 0.4
G80WDR2 SLR344-2T 2 42 88 14 40 0.47
G80WDR3 SLR344-3T 3.15 45 94 17 42.5 0.69
G80WDR5 SLR344-5T 5.3 55 118 22 50 1.46
G80WDR8 SLR344-8T 8 70 141 26.5 66.5 2.5
G80WDR15 SLR344-15T 15 97 188 34 90 5.79

Grade 80 Weld on D-Ring – G80WDR

  • Base: 16 Mn Carbon Steel.
  • Ring: Grade 80 Alloy Steel, quenched and tempered.
  • Red painted.
  • Welding must be done in accordance with DIN 5817 resp. 15429, by a qualified welder according to BS-EN 287-1.
  • Marked with WLL, material grade, manufacturers identification, CE.
  • Proof load 2 x WLL.
  • Safety factor 4 to 1.
  • Please consult George Taylor & Co. safety instruction for all welding assistance and product guidance before use.
